Energy saving 50HP PM VSD screw air compressor

Product name	Energy saving 50HP PM VSD Screw Air Compressor
Model	ZAY-50
Max Working Pressure	7/8/10 bar
Air Flow	1.86-6.2 m3/min
Motor Power	37KW/50HP
Connection	G 1-1/2
Weight	605 KG
Dimensnion(L*W*H)	1300*930*1250MM

The Energy-saving 50HP permanent magnet variable frequency screw air compressor (approximately 37KW) is an intelligent compression device that uses IE5 ultra-high energy efficiency permanent magnet synchronous motor direct drive screw host. Through the frequency converter, the displacement can be infinitely adjusted by 15% -100%, and the standard exhaust pressure covers 7-12 bar (customizable high-pressure models). It integrates a two-stage compression host, intelligent PID control system, and IoT remote monitoring module, with a pressure accuracy of ± 0.1 bar, low noise of 65 decibels, and multi machine linkage control function. It is suitable for high flow continuous operation scenarios such as automobile manufacturing, lithium battery production, injection molding, etc. Compared with traditional power frequency models, it can save more than 40% energy and extend maintenance cycle by 50%.

The Energy-saving 50HP permanent magnet variable frequency screw air compressor (approximately 37KW) achieves 15% -100% stepless flow regulation through permanent magnet synchronous motor direct drive technology (IE5 energy efficiency), saving more than 40% energy compared to traditional power frequency models; Its dual stage compression design, combined with a pressure accuracy of ± 0.1 bar, can stably output 7-10 bar compressed air. It has a low noise level of 65 decibels and a core component lifespan of 100000 hours, significantly reducing operation and maintenance costs. The built-in intelligent PID control and IoT module support remote monitoring and multi machine linkage, making it particularly suitable for continuous operation scenarios such as automobile manufacturing and lithium battery production. Its comprehensive energy-saving, stability, and intelligence advantages are outstanding.



The Energy-saving 50HP permanent magnet variable frequency screw air compressor is widely used in automotive manufacturing (welding/spraying line constant pressure gas supply), lithium battery production (polar roller press pneumatic system), injection molding (large injection molding machine power source), food and medicine (sterile packaging and fermentation tank aeration), and textile industry (high-speed jet loom cluster gas supply) due to its high efficiency, energy saving and intelligent regulation characteristics. Its 15% -100% stepless flow regulation ability can accurately match the pressure demand of 7-10 bar, especially suitable for 24-hour continuous production and working conditions with large gas fluctuations. Through permanent magnet motor direct drive and intelligent PID control, ± 0.1 bar pressure stability is achieved, which saves more than 40% energy compared to traditional models. At the same time, it supports IoT remote monitoring and multi machine joint control, significantly improving production energy efficiency. Equipment reliability.
