1-150M3/Min NO heat Adsorption Dryer for Industrial Use

1-150M3/Min NO heat Adsorption Dryer for Industrial Use

Get Latest Price
    Contact Now
    Share:

    Model No.: YX-50

    Brand: ZAKF

    Origin: Dongguan, Guangdong

    Certification: CE Certification

    Description
    aerial documentary of industrial plant area
    00:28
    Product Description

    Rated Processing Air Flow 1-150m3/min
    Inlet Pressure 0.45-1.0Mpa(0.7Mpa)
    Inlet temperature ≤40°C (38°C)
    Inlet Oil Content ≤0.08ppm(0.1mg/m3)
    Dust Grain Diameterin Outlet Air ≤60um
    Average Regenerate Air Flow 10%-22% rated processing air flow
    Dust Grain Diameterin Outlet Air -20°C~-40°C
    Pressure Drop ≤0.021 Mpa
    Absorbate Activated aluminium oxide、molecular sieve
    Regeneration Method Regeneration Method:Normal-heating
    Working Method Auto switch of two towers for 4 minor10 min,Continuous operation
    Control Method PLC control, 60min cycle of loop
    Installation Indoor,non-basis installation allowed
    Power Supply 1Ph/220V/50Hz


    Product Description

    ZAKF heatless desiccant Air Dryer is a high-efficiency compressed air purification equipment adopting pressure swing adsorption (PSA) technology. Equipped with dual-tower structure, it utilizes high-quality activated alumina and molecular sieve adsorbents to physically absorb moisture from compressed air. Without external heating source, one tower performs drying adsorption under working pressure while the other realizes desorption and regeneration with partial dry air. The automatic cyclic switching operation ensures continuous and stable supply of dry compressed air. Featuring robust all-steel frame, standardized piping and intelligent control system, this dryer achieves stable pressure dew point as low as -40℃~-60℃, effectively removing water vapor from compressed air to guarantee clean and dry air source for industrial pneumatic systems.


    Application Scenarios

    ZAKF heatless desiccant air dryers are widely applied in industries requiring high-purity dry compressed air, suitable for intermittent and continuous production conditions:
    • Pharmaceutical & Food Industry: Meet GMP production standards, eliminate moisture contamination, ensure sterile and dust-free production environment for pharmaceutical processing, food packaging and filling lines.
    • Aerospace & Military Industry: Applied in pneumatic control systems of precision parts, preventing valve stagnation and component damage caused by moisture icing under low-temperature conditions.
    • Automobile & Machinery Manufacturing: Used for auto parts processing, pneumatic tool operation and welding equipment, avoiding pipeline corrosion and equipment failure induced by humid air.
    • Electronic & Semiconductor Industry: Prevent static electricity and circuit damage caused by moisture, ensuring stable operation of precision electronic production and testing equipment.
    • General Industrial Manufacturing: Adapt to small and medium-sized factories with limited installation space, applicable to common pneumatic pipelines, spraying and packaging production lines.

    Core Selling Points

    • Stable Drying Performance: Optimized adsorption tower structure extends the contact time between air and adsorbent. Extra 30% adsorbent is configured to compensate for natural aging, maintaining long-term stable low dew point and consistent air drying quality.
    • Energy-saving & Safe Operation: Heatless regeneration design requires no heating device, lowering overall energy consumption. Simple internal structure reduces failure rate, with low carbon emission and safe operation without overheating risks.
    • Compact & Easy Installation: Integrated modular dual-tower design minimizes floor area, only 50% space of traditional dryers. It supports flexible pipeline layout and is easy to install without complicated construction.
    • Intelligent & Low Maintenance: Equipped with an intelligent automatic control system, supporting one-click start-stop and fault self-diagnosis. The adsorbent service life reaches 3-5 years, with long maintenance cycle and low daily labor & replacement cost.
    • Durable & Customizable: Thickened steel shell and high-pressure resistant pipelines enhance corrosion resistance and service life. Custom parameters such as working pressure and air handling capacity are available to meet diverse industrial demands.
